Designed to automatically remove the drainage water produced by air-conditioners.
Our Pump are can be also used for other types of water removal from refrigeration equipments, dehumidifiers, water dispensers, vending machines, ice makers, etc. where gravity drainage is possible.

  • Fully Automatic Operation
  • Snap Action Pump Switch
  • A.B.S Tank, Motor Cover and Volute
  • Low Noise Motor with Thermal Overload Protection(120¡É)
  • Stainless Steel Pump Shaft
  • 1/2¡¨ Turn Check Valve to prevent Back Flow
  • Various Models for various set-up positions
  • Fine and Modern & practical Design for Easy Installation
    •

    MODEL NO

    STANDARD HEAD
    (Meters)

    OPERATION SYSTEM

    CHECK VALVE

    SAFETY SWITCH

    SIZE
    (W×D×H)

    Water Tank Capacity
    (Liters)

    SM-4M

    4M

    Micro
    Switch

    ¡Û

    ¡â

    283x141x181

    1.8§¤

    SM-6M

    		 6M

    ¡Û

    ¡â

    SM-8M

    		 8M

    ¡Û

    ¡â

    SM-11M

    		 11M

    ¡Û

    ¡â

    366x185x240

    4.0§¤

    SM-13M

    		 13M

    ¡Û

    ¡â

    SM-16M

    		 16M

    ¡Û

    ¡â

    HS-3M

    		 3M

    P.C.B

    ¡Û



    192x86x134

    0.5§¤


    1. The above technical data were made under the circumstance of 220V, 60Hz.
       - It is available to fit the voltage of pumps to customer`s requirements.
       - If the cycle of user`s power supply is 50Hz, the flow rate and the standard head will be decreased by 10~20%.

    2. ¡Û: Built-IN, ¡â: Optional

    3. The above models and specifications can be changed without any notice for functional improvements.

    4. As a result of continuous researches and developments, new model pumps will be added in the future.
